A Comparative Study on Flexural Capacity of Reinforced Concrete Beams Reinforced with GFRP and Steel Bars

Muhammad Rafani; Tavio; Francisco Jose De Caso y Basalo

doi:10.46604/aiti.2026.16342

Authors

Muhammad Rafani Department of Civil Engineering, Institut Teknologi Sepuluh Nopember, Surabaya, Indonesia
Tavio Department of Civil Engineering, Institut Teknologi Sepuluh Nopember, Surabaya, Indonesia
Francisco Jose De Caso y Basalo Department of Civil and Architectural Engineering, University of Miami, Coral Gables, USA

DOI:

https://doi.org/10.46604/aiti.2026.16342

Keywords:

concrete beams, flexural capacity, GFRP reinforcement, moment capacity, sustainable infrastructure

Abstract

This study compares the flexural capacity of reinforced concrete (RC) beams reinforced with glass fiber-reinforced polymer (GFRP) bars and conventional steel bars. It examines how reinforcement ratio affects relative moment-capacity performance. Twelve beam specimens are tested under four-point bending with reinforcement ratios from 0.5% to 2.4%. All specimens have identical geometry, transverse reinforcement, and loading configuration. Experimental moment capacities are calculated from ultimate loads and compared with Canadian Standards Association (CSA) S806-12-based predictions for GFRP-reinforced beams. At low reinforcement ratios (ρ ≤ 1.0%), GFRP-reinforced beams develop moment capacities comparable to or higher than steel-reinforced beams because of the high tensile strength of GFRP. At higher reinforcement ratios, steel-reinforced beams achieve larger capacities due to yielding and stress redistribution. The results indicate a gradual transition zone around ρ ≈1.1-1.2%, rather than a strict threshold. CSA predictions are generally conservative, except for the lowest-ratio GFRP specimen. These findings support comparative design.

References

B. Benmokrane, S. Mousa, K. Mohamed, and M. S. Ahmed, “Physical, Mechanical, and Durability Characteristics of Newly Developed Thermoplastic GFRP Bars for Reinforcing Concrete Structures,” Construction and Building Materials, vol. 276, article no. 122200, 2021.

ACI Committee 440.1R-15, Guide for the Design and Construction of Structural Concrete Reinforced with Fiber-Reinforced Polymer (FRP) Bars, Farmington Hills, MI: American Concrete Institute, 2015.

O. I. Abdelkarim, E. A. Ahmed, H. M. Mohamed, and B. Benmokrane, “Flexural Strength and Serviceability Evaluation of Concrete Beams Reinforced with Deformed GFRP Bars,” Engineering Structures, vol. 186, pp. 282-296, 2019.

W. Xue, F. Peng, and Q. Zheng, “Design Equations for Flexural Capacity of Concrete Beams Reinforced with Glass Fiber–Reinforced Polymer Bars,” Journal of Composites for Construction, vol. 20, no. 3, article no. 04015069, 2016.

R. H. P. Akhmad and Tavio, “Influence of Seawater on Strength of Concrete Beams Strengthened with Glass Fiber Reinforced Polymer Sheet,” International Journal of GEOMATE, vol. 26, no. 117, pp. 35-42, 2024.

C. Barris, L. Torres, C. Miàs, and I. Vilanova, “Design of FRP Reinforced Concrete Beams for Serviceability Requirements,” Journal of Civil Engineering and Management, vol. 18, no. 6, pp. 843-857, 2012.

C. Farias, S. Pessi, A. Wanderlind, J. H. Piva, and E. Pavei, “Flexural Behavior of Concrete Beams Reinforced with Glass Fiber Reinforced Polymer and Steel Bars,” Revista de la Construcción, vol. 21, no. 3, pp. 506-522, 2022.

M. Rafani, A. Suhardjono, Wisnumurti, A. Wibowo, and Tavio, “A Theoretical Study of GFRP RC Beams Deflection,” Journal of Physics: Conference Series, vol. 1477, article no. 052047, 2020.

O. Gouda, A. Hassanein, and K. Galal, “Experimental and Numerical Study on the Crack Width and Deflection Performance of GFRP Reinforced Concrete Beams,” Engineering Structures, vol. 283, article no. 115721, 2023.

S. H. Alsayed, Y. A. Al-Salloum, and T. H. Almusallam, “Performance of Glass Fiber Reinforced Plastic Bars as a Reinforcing Material for Concrete Structures,” Composites Part B: Engineering, vol. 31, no. 6-7, pp. 555-567, 2000.

R. J. A. Hamad, M. A. M. Johari, and R. H. Haddad, “Mechanical Properties and Bond Characteristics of Different Fiber Reinforced Polymer Rebars at Elevated Temperatures,” Construction and Building Materials, vol. 142, pp. 521-535, 2017.

X. Ruan, C. Lu, K. Xu, G. Xuan, and M. Ni, “Flexural Behavior and Serviceability of Concrete Beams Hybrid-Reinforced with GFRP Bars and Steel Bars,” Composite Structures, vol. 235, article no. 111772, 2020.

H.-L. Dong, W. Zhou, and Z. Wang, “Flexural Performance of Concrete Beams Reinforced with FRP Bars Grouted in Corrugated Sleeves,” Composite Structures, vol. 215, pp. 49-59, 2019.

C. Lu, Z. Qi, Y. Zheng, G. Xuan, and Y. Yan, “Long-Term Tensile Performance of GFRP Bars in Loaded Concrete and Aggressive Solutions,” Journal of Building Engineering, vol. 64, article no. 105587, 2023.

T. D’Antino, M. A. Pisani, and C. Poggi, “Effect of the Environment on the Performance of GFRP Reinforcing Bars,” Composites Part B: Engineering, vol. 141, pp. 123-136, 2018.

Y. Sun, Z. Jin, X. Zhang, and B. Pang, “Degradation of GFRP Bars in Alkaline Environments: An Experimental and Molecular Dynamics Study,” Journal of Building Engineering, vol. 77, article no. 107449, 2023.

D. Jia, Q. Guo, J. Mao, J. Lv, and Z. Yang, “Durability of Glass Fibre-Reinforced Polymer (GFRP) Bars Embedded in Concrete under Various Environments. I: Experiments and Analysis,” Composite Structures, vol. 234, article no. 111687, 2020.

S. Al Omar and A. Abdelhadi, “Comparative Life-Cycle Assessment of Steel and GFRP Rebars for Procurement Sustainability in the Construction Industry,” Sustainability, vol. 16, no. 10, article no. 3899, 2024.

S. Sbahieh, G. McKay, and S. G. Al-Ghamdi, “A Comparative Life Cycle Assessment of Fiber-Reinforced Polymers as a Sustainable Reinforcement Option in Concrete Beams,” Frontiers in Built Environment, vol. 9, article no. 1194121, 2023.

H. Fergani, M. Di Benedetti, C. M. Oller, C. Lynsdale, and M. Guadagnini, “Durability and Degradation Mechanisms of GFRP Reinforcement Subjected to Severe Environments and Sustained Stress,” Construction and Building Materials, vol. 170, pp. 637-648, 2018.

M. Inman, E. R. Thorhallsson, and K. Azrague, “A Mechanical and Environmental Assessment and Comparison of Basalt Fibre Reinforced Polymer (BFRP) Rebar and Steel Rebar in Concrete Beams,” Energy Procedia, vol. 111, pp. 31-40, 2017.

K. Pender and L. Yang, “Glass Fibre Composites Recycling Using the Fluidised Bed: A Comparative Study into the Carbon Footprint in the UK,” Sustainability, vol. 16, no. 3, article no. 1016, 2024.

G. Dhinakaran, S. Gowrisankar, and A. Jeyasehar, “Life Cycle Cost Analysis of Glass Fiber Reinforced Polymer Reinforced Concrete Beam,” Asian Journal of Civil Engineering, vol. 17, no. 3, pp. 315–323, 2016.

T. Cadenazzi, H. Lee, P. Suraneni, S. Nolan, and A. Nanni, “Evaluation of Probabilistic and Deterministic Life-Cycle Cost Analyses for Concrete Bridges Exposed to Chlorides,” Cleaner Engineering and Technology, vol. 4, article no. 100247, 2021.

H. Tran, T. Nguyen-Thoi, and H.-B. Dinh, “State-of-the-Art Review of Studies on the Flexural Behavior and Design of FRP-Reinforced Concrete Beams,” Materials, vol. 18, no. 14, article no. 3295, 2025.

H. Tran and T. Nguyen-Thoi, “Flexural Behavior of Beams Reinforced with FRP Bars: Test Database, Design Guideline Assessment, and Reliability Evaluation,” Buildings, vol. 15, no. 18, article no. 3373, 2025.

Canadian Standards Association, CSA S806:12 (R2021): Design and Construction of Building Structures with Fibre-Reinforced Polymers. Toronto, ON, Canada: CSA Group, 2012, reaffirmed 2021.

Tavio, M. Rafani, I. G. P. Raka, and V. Ratnasari, “Flexural Capacity Predictions and Comparisons of GFRP Reinforced Beams,” Journal of Physics: Conference Series, vol. 1477, article no. 052049, 2020.

Z. Ummah and Tavio, “Proposed Formulation for Predicting Deflections of CFRP-RC Beams,” International Journal of GEOMATE, vol. 25, no. 111, pp. 138-144, 2023.

M. Rafani, Tavio, and F. J. D. C. Basalo, “Understanding Deflection in GFRP-RC Beams: A Systematic Review of Parameters, Models, and Code Implications,” Civil Engineering and Architecture, vol. 14, no. 1, pp. 82-90, 2026.
